| Model: Pentium Gold G6405 (Tray Box) |
| Socket Supported FCLGA1200 |
| Speed 4.10 GHz, Cores- 2 & Threads- 4 |
| 4M Intel Smart Cache |
| Intel UHD Graphics 610 |
- Stock: In Stock
| Key Features | |
| key1 | Model: Pentium Gold G6405 (Tray Box) |
| key2 | Socket Supported FCLGA1200 |
| key3 | Speed 4.10 GHz, Cores- 2 & Threads- 4 |
| key4 | 4M Intel Smart Cache |
| key5 | Intel UHD Graphics 610 |
| Basic Information | |
| Base Frequency | 4.10 GHz |
| Cache | 4 MB Intel Smart Cache |
| Cores | 2 |
| Threads | 4 |
| Default TDP | 58 W |
| Memory Specifications | |
| Maximum Speed | 41.6 GB/s |
| Type | DDR4-2666 |
| Max Number of Channels | 2 |
| Maximum Size | 128 GB |
| Graphics Specifications | |
| Max Resolution | Max Resolution (HDMI): 4096x2160@30Hz Max Resolution (DP): 4096x2304@60Hz Max Resolution (eDP - Integrated Flat Panel): 4096x2304@60Hz |
| Max Video Memory | 64 GB |
| Processor Graphics | Intel UHD Graphics 610 |
| Base Frequency | 350 MHz |
| Max Dynamic Frequency | 1.05 GHz |
| Warranty Information | |
| Manufacturing Warranty | 03 Years (No Warranty for Fan or Cooler) |
Intel Pentium Gold G6405 Coffee Lake Processor
Intel Pentium Gold G6405 Processor – 10th Gen Budget CPU with Integrated Graphics. The Intel Pentium Gold G6405 is a dependable 10th Gen dual-core processor built on Intel's Coffee Lake microarchitecture. Operating at a base clock speed of 4.10 GHz, it delivers fast performance for daily computing tasks, such as browsing, office work, HD media playback, and light multitasking.
Equipped with Hyper-Threading technology, this processor offers 2 cores and 4 threads, allowing smoother performance even in multi-threaded applications. With 4MB Intel Smart Cache and built on the 14nm process, it ensures efficient data processing and power usage.
Integrated UHD Graphics – No Need for a Separate GPU
The Pentium G6405 includes Intel UHD Graphics 610, which supports up to 3 displays with a maximum resolution of 4096 x 2304 @ 60Hz—ideal for users who don’t need a dedicated graphics card.
Key Specifications:
- Base Clock: 4.10 GHz
- Cores/Threads: 2 Cores, 4 Threads
- Cache: 4MB Intel Smart Cache
- TDP: 58W
- Bus Speed: 8 GT/s DMI
- Lithography: 14nm Process Technology
- Socket Compatibility: LGA 1200
- Memory & Expansion Support:
- Supports DDR4-2666 MHz dual-channel memory
- Max memory size up to 128GB (depends on motherboard)
- Compatible with Intel 300-series motherboards (may require BIOS update)
- PCI Express 3.0 support with up to 16 lanes (configurations: 1x16, 2x8, 1x8+2x4)
Advanced Intel Technologies:
- Intel Virtualization Technology (VT-x, VT-d)
- Intel Optane Memory Support
- Enhanced Intel SpeedStep Technology
- Intel Identity Protection Technology
- Intel Turbo Boost 2.0
Warranty Information:
The Intel Pentium Gold G6405 processor comes with a 3-year official warranty (Note: Warranty does not cover the included cooler or fan).
